March Replacement Pump Specifications:

• Max Temperature – 230 F / 110C
• Static PSI – 145.0 / 10 Bar
• Threaded Fittings
• Inlet / Outlet – 1/2” x 1/2”
• Food Grade

Application:

The March Replacement Pump is made with a DC brushless motor with energy efficiency technology:

• Maximum power point tracking (MPPT)
• Replacement option for the El SID and the 809-BR 12V & 24V Mag Drive March Pump
• Pairs perfectly with the 24V 2 Amp AC/DC Adapter

Features of the March Replacement Pump:

• DC brushless motor with energy efficiency technology by micro processor
• High efficient ECM brushless DC motor can sustain a continuous 24-hour workload with life expectancy of well over 20,000 hours.
• Durable permanent magnetic rotor/impeller and fine ceramic shaft
• Advanced magnetic drive technology with static-impeller

Dry-running protection:

When drive circuitry detects no or little liquid in the pump chamber, it will stop the pump to prevent damage. Then you can restart the March Replacement Pump manually by disconnecting and reconnecting it to the power supply.

Over voltage protection:

If the voltage exceeds 28V, the pump will auto-protect and shut off the power supply. When the voltage falls below 28V, the pump will restart automatically.

Overload protection function:

When the current exceeds the rated current, such as can arise when the impeller jams due to debris, the pump will automatically stop to prevent damage.  The pump will restart when the current returns to normal.

Areas of use for the March Replacement Pump:

• Beer Brewing
• Liquid Transfer
• Hot Water Circulation
• Radiant Floor Heating
• Air Energy Water Heater
• Portable Power Supplies
• Hot Pump Air Conditioner
